Oil Bath (Circulator)

Regular – GMP - Model

  • Double walled in construction Inner made of SS 304 and Exterior GI Powder coated in REGULAR MODEL.
  • Inner made of SS 316/SS 304 & Exterior SS 304 Matt/Buff finish in GMP MODEL.
  • The Inner tank is completely welded for leak proof durability.
  • The high grade compressed cerawool & combination of glasswool insulation provided in between the wall to minimize the heat loss.
  • The Temp. is being controlled by Automatic Autotuning Microprocessor based PID Temp. Controller with Dual Digital Indicator and PT-100 sensor.
  • The unit consist with Pump cum Stirring Assembly for Internal as well as External circulation & better Temp. uniformity. The External Head upto 5/6 feet only.
  • Pump Output :- 5/7 Ltr. Per Minute.
  • Specially designed Long Life Stainless Steel Heater.
  • A drainage cock is provided at side of the bath for outlet purpose.
Oil Bath Cirulator
Cat No.
Inner Size (L x W x D)
Temp. Accuracy
Temp. Range
CIC - 105 A
10" x 10" x 8"
± 1oC to ± 2oC
50oC to 300oC
CIC - 105 B
12" x 12" x 10"
± 1oC to ± 2oC
50oC to 300oC
CIC - 105 C
14" x 12" x 12"
± 1oC to ± 2oC
50oC to 300oC
Note: Pump Output Flow Rate Of More Than 7 Ltrs. P/Minute Can Be Provided As Per Your Requirement.
Flame Proof Oil Bath Circulators available

Optional

  • ALARM facility to alert incase of Temp. Overshoot.
  • PRINTER OUTPUT facility required to record PV, SV, Actual Date/Time with variable print time interval, 5000 line memory & Audio alarm facility in case of memory full.
  • Imported Thermic Fluid Oil can be supplied at extra cost.
  • Flexible SS 304 braided hose pipe with insulation cover can be provided.
  • Low level of oil detection with Audio Alarm facility
